# Integration of TCRs, CPM and Ocean Tokens with Solidity ``` name: Integration of TCRs, CPM, and Ocean tokens with Solidity type: development status: initial draft editor: Fang Gong collaborator: Aitor Argomaniz date: 08/06/2018 ``` ## Further Documentation * [TCR Owner's Manual](owners_manual.md) ## Objective In this project, we put following modules together: * **TCRs**: users create challenges and resolve them through voting to maintain registries; * **Ocean Tokens**: the intrinsic tokens circulated inside Ocean network, which is used in the voting of TCRs; * **Curated Proofs Market**: the core marketplace where people can transact with each other and curate assets through staking with Ocean tokens. ## Public Interface The project exposes the following public interfaces: ### Token Curated Registry (OceanRegistry.sol) ```solidity //Allows a user to start an application. Takes tokens from user and sets apply stage end time. function apply(bytes32 _listingHash, uint _amount, string _data); // Allows the owner of a listingHash to increase their unstaked deposit. function deposit(bytes32 _listingHash, uint _amount); //Allows the owner of a listingHash to decrease their unstaked deposit. function withdraw(bytes32 _listingHash, uint _amount); // Allows the owner of a listingHash to remove the listingHash from the whitelist function exit(bytes32 _listingHash); // Starts a poll for a listingHash which is either in the apply stage or already in the whitelist. function challenge(bytes32 _listingHash, string _data); // Updates a listingHash’s status from ‘application’ to ‘listing’ or resolves a challenge if one exists. function updateStatus(bytes32 _listingHash); // Called by a voter to claim their reward for each completed vote. function claimReward(uint _challengeID, uint _salt); // Calculates the provided voter’s token reward for the given poll. function voterReward(address _voter, uint _challengeID, uint _salt); // Determines whether the given listingHash be whitelisted. function canBeWhitelisted(bytes32 _listingHash); // Returns true if the provided listingHash is whitelisted function isWhitelisted(bytes32 _listingHash); // Determines the number of tokens awarded to the winning party in a challenge. function determineReward(uint _challengeID); ``` ### Marketplace (OceanMarket.sol) ```solidity // Register data assets function register(bytes32 assetId, uint256 price) public returns (bool success); // consumer can make payment function sendPayment(bytes32 _paymentId, address _receiver, uint256 _amount, uint256 _expire) public returns (bool); // release fund to provider - must be called by OceanAuth contract function releasePayment(bytes32 _paymentId) public isLocked(_paymentId) returns (bool); // refund payment - must be called by OceanAuth contract function refundPayment(bytes32 _paymentId) public isLocked(_paymentId) returns (bool); // verify the payment is received function verifyPaymentReceived(bytes32 _paymentId) public view returns (bool); // Generate Unique Id for asset using input string parameter function generateStr2Id(string contents) public pure returns (bytes32); // Generate Unique Id for asset using input bytes parameter function generateBytes2Id(bytes contents) public pure returns (bytes32); // Market checks the TCR voting results function checkListingStatus(bytes32 listing) public view returns(bool); // Market changes the status of TCR according to voting result function changeListingStatus(bytes32 listing, bytes32 assetId) public returns(bool); ``` ### On-Chain Authorization (OceanAuth.sol) ```solidity // consumer request access to resource function initiateAccessRequest(bytes32 resourceId, address provider, string pubKey, uint256 timeout) public returns (bool); // provider commit the access request function commitAccessRequest(bytes32 id, bool isAvailable, uint256 expirationDate, string discovery, string permissions, string accessAgreementRef, string accessAgreementType) public onlyProvider(id) isAccessRequested(id) returns (bool); // consumer can cancel the access request function cancelAccessRequest(bytes32 id) public isAccessCommitted(id) onlyConsumer(id); // provider deliver the access token function deliverAccessToken(bytes32 id, bytes encryptedAccessToken) public onlyProvider(id) isAccessCommitted(id) returns (bool); // provider verify the delivery of JWT access token function verifyAccessTokenDelivery(bytes32 id, address _addr, bytes32 msgHash, uint8 v, bytes32 r, bytes32 s) public onlyProvider(id) isAccessComitted(id) returns (bool); ``` ### Query functions ```solidity // provider query the temp public key function getTempPubKey(bytes32 id) public view onlyProvider(id) isAccessCommitted(id) returns (string); // consumer query the encrypted access token function getEncryptedAccessToken(bytes32 id) public view onlyConsumer(id) isAccessCommitted(id) returns (bytes); // provider uses this function to verify the signature comes from the consumer function isSigned(address _addr, bytes32 msgHash, uint8 v, bytes32 r, bytes32 s) public pure returns (bool); // verify the status of access request function verifyCommitted(bytes32 id, uint256 status) public view returns (bool); // Return true or false if an Asset is active given the assetId function checkAsset(bytes32 assetId) public view returns (bool); // Retrieve the price of asset function getAssetPrice(bytes32 assetId) public view returns (uint256); ``` ### Events ```solidity // OceanMarket Events event AssetRegistered(bytes32 indexed _assetId, address indexed _owner); event PaymentReceived(bytes32 indexed _paymentId, address indexed _receiver, uint256 _amount, uint256 _expire); event PaymentReleased(bytes32 indexed _paymentId, address indexed _receiver); event PaymentRefunded(bytes32 indexed _paymentId, address indexed _sender); // OceanAuth Events event AccessConsentRequested(bytes32 _id, address _consumer, address _provider, bytes32 _resourceId, uint _timeout, string _pubKey); event AccessRequestCommitted(bytes32 _id, uint256 _expirationDate, string _discovery, string _permissions, string _accessAgreementRef); event AccessRequestRejected(address _consumer, address _provider, bytes32 _id); event AccessRequestRevoked(address _consumer, address _provider, bytes32 _id); event EncryptedTokenPublished(bytes32 _id, bytes _encryptedAccessToken); event AccessRequestDelivered(address _consumer, address _provider, bytes32 _id); ``` ## File Structure There are several folders and each includes solidity source files for each module: * **auth**: OceanAuth contract for authorization; * **plcrvoting**: Partial Lock Commit Reveal Voting System; * **tcr**: the TCRs related files; * **token**: Ocean tokens based on ERC20 standard; * **zeppelin**: the library files from OpenZeppelin; * **Oceanmarket.sol**: curated proofs market (*on-going work*); * **Migrations.sol**: default contract for migration. ## Architecture of Solidity Market Contract * [First draft of UML class diagram](files/Smart-Contract-UML-class-diagram.pdf)
