# Homebridge Tasmota Control [![verified-by-homebridge](https://img.shields.io/badge/homebridge-verified-purple)](https://github.com/homebridge/homebridge/wiki/Verified-Plugins) [![npm](https://shields.io/npm/dt/homebridge-tasmota-control?color=purple)](https://www.npmjs.com/package/homebridge-tasmota-control) [![npm](https://shields.io/npm/v/homebridge-tasmota-control?color=purple)](https://www.npmjs.com/package/homebridge-tasmota-control) [![npm](https://img.shields.io/npm/v/homebridge-tasmota-control/beta.svg?style=flat-square)](https://www.npmjs.com/package/homebridge-tasmota-control) [![GitHub pull requests](https://img.shields.io/github/issues-pr/grzegorz914/homebridge-tasmota-control.svg)](https://github.com/grzegorz914/homebridge-tasmota-control/pulls) [![GitHub issues](https://img.shields.io/github/issues/grzegorz914/homebridge-tasmota-control.svg)](https://github.com/grzegorz914/homebridge-tasmota-control/issues) Supports My Work ## Package Requirements | Package | Installation | Role | Required | | --- | --- | --- | --- | | [Homebridge](https://github.com/homebridge/homebridge) | [Homebridge Wiki](https://github.com/homebridge/homebridge/wiki) | HomeKit Bridge | Required | | [Config UI X](https://github.com/homebridge/homebridge-config-ui-x) | [Config UI X Wiki](https://github.com/homebridge/homebridge-config-ui-x/wiki) | Homebridge Web User Interface | Recommended | | [Tasmota Control](https://www.npmjs.com/package/homebridge-tasmota-control) | [Plug-In Wiki](https://github.com/grzegorz914/homebridge-tasmota-control/wiki) | Homebridge Plug-In | Required | ## Warning * For plugin < v1.8.0 use Homebridge UI <= v5.5.0. * For plugin >= v1.8.0 use Homebridge UI >= v5.13.0. ## About The Plugin * Plugin work with Tasmota v6.0.0 and abowe. * Support Mitsubishi HVAC: * Precompiled ESP firmware for `MiElHVAC` are in `firmware` folder. * If You need firmware for specific `ESP` please go to [Firmware for MiElHVAC](https://github.com/grzegorz914/homebridge-tasmota-control/issues/18) and meke request. * Heater Cooler: * Power `ON/OFF`. * Operating mode `AUTO/HEAT/COOL`. * Temperature `HEATING/COOLING/AUTO`. * Fan speed `OFF/QUIET/1/2/3/4/AUTO`. * Swing mode `AUTO/SWING`. * Physical lock controls `LOCK/UNLOCK`. * Temperature display unit `°F/°C`. * Buttons: * For direct device control. * Power `ON/OFF`. * Operating mode `HEAT/DRY/COOL/FAN/AUTO`. * Fan speed `OFF/QUIET/1/2/3/4/AUTO`. * Vane H `LEFT/LEFT MIDDLE/CENTER/RIGHT MIDDLE/RIGHT/SPLIT/SWING`. * Vane V `AUTO/UP/UP MIDDLE/CENTER/DOWN MIDDLE/DOWN/SWING`. * Air direction `INDIRECT/DIRECT/EVEN`. * Prohibit `POWER/MODE/TEMPERATURE/ALL`. * Physical lock controls `LOCK/UNLOCK`. * Presets `SET/UNSET`. * Sensors: * For automation and notifications. * State sensors: * Power `ON/OFF`. * Operating mode `HEAT/DRY/COOL/FAN/AUTO`. * Fan speed `OFF/QUIET/1/2/3/4/AUTO`. * Vane H `AUTO/1/2/3/4/5/SPLIT/SWING`. * Vane V `AUTO/1/2/3/4/5/SWING`. * Air direction `INDIRECT/DIRECT/EVEN`. * Physical lock controls `LOCK/UNLOCK`. * Presets `ACTIV/UNACTIV`. * Operation stage `NORMAL/DEFROST/PREHEAT/STANDBY`. * Fan stage `OFF/QUIET/1/2/3/4/5`. * Mode stage `AUTO OFF/AUTO FAN/AUTO HEAT/AUTO COOL`. * Remote temperature. * Temperature sensors: * Room temperature. * Outdoor temperature. * Functions: * Frost protect * Supported relay devices: * Light - `Power ON/OFF`, `Dimmer`, `Color Temperature`, `Hue`, `Saturation` * Outlet - `Power ON/OFF` * Switch - `Power ON/OFF` * Fan - `Fan ON/OFF`, `Speed`, `Light ON/OFF` * Supported Sensors: * Temperature - `Temperature`, `Dew Point`, `Reference`, `Obj`, `Amb` * Humidity * Carbon Dioxyde * Ambient Light * Motion * Power * Energy * Current * Voltage * Power Factor * Frequency ### Configuration * Run this plugin as a [Child Bridge](https://github.com/homebridge/homebridge/wiki/Child-Bridges) (Highly Recommended), this prevent crash Homebridge if plugin crashes. * Install and use [Homebridge Config UI X](https://github.com/homebridge/homebridge-config-ui-x/wiki) to configure this plugin (Highly Recommended). * The `sample-config.json` can be used as an alternative, make a backup copy before making any changes.

| Key | Description | | --- | --- | | `name` | Here set the accessory *Name* to be displayed in *Homebridge/HomeKit*. | | `host` | Here set the *Hsostname or Address IP* of the Device.| | `auth` | If enabled, authorizatins credentials will be used for login. | | `user` | Here set the authorization *Username*. | | `passwd` | Here set the authorization *Password*. | | `disableAccessory` | If enabled, the accessory will be disabled. | | `miElHvac.heatDryFanMode` | Here select the operatiing mode for `Heat`, only for Mitsubishio AC. | | `miElHvac.coolDryFanMode` | Here select the operatiing mode for `Cool`, only for Mitsubishio AC. | | `miElHvac.autoDryFanMode` | Here select the operatiing mode for `Auto`, only for Mitsubishio AC. | | `miElHvac.temperatureSensor` | This enable extra `Room` temperature sensor to use with automations in HomeKit app. | | `miElHvac.temperatureSensorOutdoor` | This enable extra `Outdoor` temperature sensor to use with automations in HomeKit app. | | `miElHvac.remoteTemperatureSensor` | Object of remote temperature sensor. | | `miElHvac.remoteTemperatureSensor.enable` | This activate the function. | | `miElHvac.remoteTemperatureSensor.path` | Here set the path to the temperature sensor, the request need to return value. | | `miElHvac.remoteTemperatureSensor.refreshInterval` | Here set remote sensor refresh interval. | | `miElHvac.remoteTemperatureSensor.auth` | If enabled, authorizatins credentials will be used for remote sensor. | | `miElHvac.remoteTemperatureSensor.user` | Here set the authorization *Username*. | | `miElHvac.remoteTemperatureSensor.passwd` | Here set the authorization *Password*. | | `miElHvac.presets` | Array of presets sensors. | | `miElHvac.presets.name` | Here You can schange the `Preset Name` which is exposed to the `Homebridge/HomeKit`. | | `miElHvac.presets.mode` | Here set the operation mode. | | `miElHvac.presets.setTemp` | Here set the target temperature. | | `miElHvac.presets.fanSpeed` | Here set the fan speed. | | `miElHvac.presets.swingV` | Here set the vane vertical direction. | | `miElHvac.presets.swingH` | Here set the vane horizontal direction. | | `miElHvac.presets.displayType` | Here select display type in HomeKit, `0 - None/Disabled`, `1 - Outlet`, `2 - Switch`, `3 - Motion Sensor`, `4 - Occupancy Sensor`, `5 - Contact Sensor`. | | `miElHvac.buttons` | Array of buttons sensors. | | `miElHvac.buttons.name` | Here set `Button Name` which You want expose to the `Homebridge/HomeKit`. | | `miElHvac.buttons.mode` | Here select button function mode. | | `miElHvac.buttons.displayType` | Here select display type in HomeKit, `0 - None/Disabled`, `1 - Outlet`, `2 - Switch`, `3 - Motion Sensor`. | | `miElHvac.buttons.namePrefix` | Here enable/disable the accessory name as a prefix for button name. | | `miElHvac.sensors` | Array of sensors sensors. | | `miElHvac.sensors.name` | Here set `Sensor Name` which You want expose to the `Homebridge/HomeKit`. | | `miElHvac.sensors.mode` | Here select sensor function mode. | | `miElHvac.sensors.displayType` | Here select display type in HomeKit, `0 - None/Disabled`, `1 - Motion Sensor`, `2 - Occupancy Sensor`, `3 - Contact Sensor`. | | `miElHvac.sensors.namePrefix` | Here enable/disable the accessory name as a prefix for sensor name. | | `miElHvac.frostProtect` | Object of frost protect function. | | `miElHvac.frostProtect.enable` | This activate frost protect function. | | `miElHvac.frostProtect.lowTemp` | Here set the low temperature at which device start to frost protect. | | `miElHvac.frostProtect.highTemp` | Here set the high temperature at which device start to frost protect. | | `relaysNamePrefix` | Here enable/disable the accessory name as a prefix for relays name. | | `relaysDisplayType` | Here select characteristic display type for relays which are exposed in the HomeKit app. | | `lightsNamePrefix` | Here enable/disable the accessory name as a prefix for lights name. | | `fansNamePrefix` | Here enable/disable the accessory name as a prefix for fan name. | | `sensorsNamePrefix` | Here enable/disable the accessory name as a prefix for sensors name. | | `loadNameFromDevice` | If enabled, the accessory name will be loaded direct from device. | | `refreshInterval` | Here set the data refresh time in (sec). | | `log.deviceInfo` | If enabled, log device info will be displayed by every connections device to the network. | | `log.success` | If enabled, success log will be displayed in console. | | `log.info` | If enabled, info log will be displayed in console. | | `log.warn` | If enabled, warn log will be displayed in console. | | `log.error` | If enabled, error log will be displayed in console. | | `log.debug` | If enabled, debug log will be displayed in console. |
