Skeletal-Animation-System

A standalone, stateless, dual quaternion based skeletal animation system built with interactive applications in mind.

placeholder

Introduction

skeletal-animation-system aims to give the user a flexible module for managing skeletal animations across different 3d models and bone groups.

skeletal-animation-system aims to provide a sane API for starting, stopping and interpolating skeletal animations.

It supports blending between your previous and current animation when you switch animations. It also supports splitting your model into different bone groups such as the upper and lower body, allowing you to, for example, play a walking animation for your legs while playing a punch animation for your upper body.

skeletal-animation-system does not maintain an internal state, but instead lets the modules consumer track things such as the current animation and the current clock time.

I use matrices and not dual quaternions

The first versions of skeletal-animation-system uses matrices instead of dual quaternions.

The issue there was that blending matrices can lead to unexpected artifacts.

So we switched to dual quaternions and completely dropped support for matrices.

However, if you use matrices you can still make use of skeletal-animation-system.

  1. Convert your matrices into dual quaternions once when you first load your model.
  2. Use skeletal-animation-system to determine your pose dual quaternions
  3. Convert your pose dual quaternions back into matrices before each render
  4. Use your newly created matrices for skinning

The 3rd step here means that you're doing some extra work on the CPU, but this hopefully bridges the gap for you until you can move to dual quaternion based skinning.

This API is still experimental and will evolve as we use it and realize the kinks.

To Install

$ npm install --save skeletal-animation-system

Usage

var animationSystem = require('skeletal-animation-system')
// Parsed using collada-dae-parser or some other parser
var parsedColladaModel = require('./parsed-collada-model.json')

// Keyframe data for all joints.
// @see `github.com/chinedufn/blender-actions-to-json` for an example format
var lowerBodyKeyframes = {...}
var upperBodyKey = {...}

// Convert our joint names into their associated joint index number
// This number comes from collada-dae-parser
// (or your parser of choice)
var upperBodyJointNums = [0, 1, 5, 6, 8]
var lowerBodyJointNums = [2, 3, 4, 7, 9]

// Our options for animating our model's upper body
var upperBodyOptions = {
  currentTime: 28.24,
  jointNums: upperBodyJointsNums,
  blendFunction: function (dt) {
    // Blend animations linearly over 2.5 seconds
    return 1 / 2.5 * dt
  },
  currentAnimation: {
    keyframes: currentAnimKeyframes,
    startTime: 25
  },
  previousAnimation: {
    keyframes: previousAnimKeyframes,
    startTime: 24.5
  }
}

// Our options for animating our model's lower body
var lowerBodyOptions = {
  currentTime: 28.24,
  jointNums: lowerBodyJointNums,
  currentAnimation: {
    keyframes: currentAnimKeyframes,
    startTime: 24.3,
    noLoop: true
  }
}

var interpolatedUpperBodyJoints = animationSystem
.interpolateJoints(upperBodyOptions).joints

var lowerBodyData = animationSystem
.interpolateJoints(lowerBodyOptions)
var interpolatedLowerBodyJoints = lowerBodyData.joints

console.log(lowerBodyData.currentAnimationInfo)
// => {lowerKeyframeNumber: 5, upperKeyframeNumber: 6}

// You now have your interpolated upper and lower body dual quaternions (joints).
// You can pass these into any vertex shader that
// works with dual quaternions

// If you're just getting started and you still need matrices you
// can convert these into matrices using dual-quat-to-mat4
//  @see https://github.com/chinedufn/dual-quat-to-mat4

Tutorials

WebGL Skeletal Animation Sound Effects Tutorial

Attaching objects to bones

WebGL Skeletal Animation Tutorial

API

animationSystem.interpolateJoints( options ) -> Object

options

Optional

Type: object

// Example overrides
var myOptions = {
  // TODO:
}
interpolatedJoints = animationSystem.interpolateJoints(myOptions)

currentTime

Type: Number

Default: 0

The current number of seconds elapsed. If you have an animation an loop, this will typically be the sum of all of your loops time deltas

// Example of tracking current time
var currentTime = 0
function animationLoop (dt) {
  currentTime += dt
}

keyframes

Type: Object

Default: {}

jointNums

Type: Array

An array of joint indices that you would like to interpolate.

Say your model has 4 joints. To interpolate the entire model you would pass in [0, 1, 2, 3]. To only interpolate two of the joints you might pass in [0, 2], or any desired combination.

These joint indices are based on the order of the joints in your keyframes

blendFunction

Type: Function

Default: Blend linearly over 0.2 seconds

A function that accepts a time elapsed in seconds and returns a value between 0 and 1.

This returned value represents the weight of the new animation.

function myBlendFunction (dt) {
  // Blend the old animation into the new one linearly over 5 seconds
  return 0.2 * dt)
}

currentAnimation

Type: Object

An object containing parameters for the current animation

If you supply a previous animation your current animation will be blended in using your blendFunction

var currentAnimation = {
  keyframes: {0: [..], 1.66666: [...]}
  startTime: 10
}
currentAnimation.keyframes

Type: Array

{
  "0": [
    [1, 0, 0, 0, 0, 1, 0, 0, 0, 0, 1, 0, 0, 0, 0, 1],
    [1, 0, 0, 0, 0, 1, 0, 0, 0, 0, 1, 0, 0, 0, 0, 1],
    [1, 0, 0, 0, 0, 1, 0, 0, 0, 0, 1, 0, 0, 0, 0, 1]
  ],
  "1.33333": [
    [1, 0, 0, 0, 0, 1, 0, 0, 0, 0, 1, 0, 0, 0, 2, 1],
    [1, 0, 0, 0, 0, 1, 0, 0, 0, 0, 1, 0, 0, 0, 2, 1],
    [1, 0, 0, 0, 0, 1, 0, 0, 0, 0, 1, 0, 0, 0, 5, 1]
  ]
}

Pose matrices for each joint in the model, organized by the animation time (0 and 1.33333 are seconds)

currentAnimation.startTime

Type: Number

The time in seconds that your current animation was initiated. This gets compared with the currentTime in order to interpolate your joint data appropriately.

currentAnimation.noLoop

Type: Boolean

Whether or not your animation should loop. For example, let's say you are 13 seconds into a 4 second animation.

If noLoop === true then you will be playing the frame at the 4th second.

If noLoop === false then you will be playing the frame at the 1st second.

previousAnimation

An object containing parameters for the previous animations. Your previous animation gets blended out using your blendFunction while your current animation gets blended in.

Type: Object

previousAnimation.keyframes

Type: Array

{
  "0": [
    [1, 0, 0, 0, 0, 1, 0, 0, 0, 0, 1, 0, 0, 0, 0, 1],
    [1, 0, 0, 0, 0, 1, 0, 0, 0, 0, 1, 0, 0, 0, 0, 1],
    [1, 0, 0, 0, 0, 1, 0, 0, 0, 0, 1, 0, 0, 0, 0, 1]
  ],
  "1.33333": [
    [1, 0, 0, 0, 0, 1, 0, 0, 0, 0, 1, 0, 0, 0, 2, 1],
    [1, 0, 0, 0, 0, 1, 0, 0, 0, 0, 1, 0, 0, 0, 2, 1],
    [1, 0, 0, 0, 0, 1, 0, 0, 0, 0, 1, 0, 0, 0, 5, 1]
  ]
}

Pose matrices for each joint in the model, organized by the animation time (0 and 1.33333 are seconds)

previousAnimation.startTime

Type: Number

The time in seconds that your previous animation was initiated. This is used in order to blend in the current animation.

Returned data

// Example
{
  joints: [...],
  currentAnimationInfo: {
    lowerKeyframeNumber: 0,
    upperKeyframeNumber:: 1
  }
}
