# UI5 Class Parser Parser package for UI5 based projects Primarely used by `ui5plugin-linter` package and Visual Studio Code SAPUI5 Extension --- Any support is highly appreciated!
[

](https://www.paypal.com/donate/?hosted_button_id=HPZ5FA8C3KJ6W) [

](https://github.com/sponsors/iljapostnovs) [

](https://donate.cafe/iljapostnovs) --- # Summary - [Configuration](#configuration) - [RC and package.json](#rc-and-packagejson) - [Config interface](#config-interface) - [Config default values](#config-default-values) - [Parser instantiation logic](#parser-instantiation-logic) - [Additional Workspaces](#additional-workspaces) - [Proxy Workspaces](#proxy-workspaces) - [Node projects](#node-projects) - [TS vs JS](#ts-vs-js) - [Initialization](#initialization) - [Folder exclusions](#folder-exclusions) - [How to use](#how-to-use) ## Configuration ### RC and package.json Configuration can be done in `package.json` or in any of `rc` file types: - `.ui5pluginrc` - `.ui5pluginrc.json` - `.ui5pluginrc.yaml` - `.ui5pluginrc.yml` - `.ui5pluginrc.js` For simplicity purposes all examples are written for `package.json`, but it works the same way for all file types. ### Config interface ```ts interface IUI5PackageConfigEntry { ui5?: IUI5ParserEntry; } interface IUI5ParserEntry { ui5parser?: IUI5ParserEntryFields; } interface IUI5ParserEntryFields { ui5version?: string; excludeFolderPatterns?: string[]; dataSource?: string; rejectUnauthorized?: boolean; libsToLoad?: string[]; additionalWorkspaces?: string[]; nodeProjects?: string[]; proxyWorkspaces?: string[]; } ``` ### Config default values Default `package.json` or `rc` file config looks as follows: ```jsonc { "ui5": { "ui5parser": { // UI5 Version for standard library metadata preload from ui5.sap.com. If no patch level is added, latest patch will be loaded and used. "ui5version": "1.120", // Folder GLOB patterns which should be excluded from reading by parser "excludeFolderPatterns": ["**/resources/**", "**/dist/**", "**/node_modules/**"], // Source for standard library metadata preload "dataSource": "https://ui5.sap.com/", // For HTTP requests to dataSource "rejectUnauthorized": false, // List of libraries to be loaded "libsToLoad": [ "sap.m", "sap.ui.comp", "sap.f", "sap.ui.core", "sap.ui.commons", "sap.ui.export", "sap.ui.layout", "sap.ui.support", "sap.ui.table", "sap.ui.unified", "sap.ushell", "sap.tnt", "sap.suite.ui.microchart" ], //Handy to add additional workspace paths if e.g. library is outside of CWD. See "Additional workspaces" section for more details "additionalWorkspaces": ["../MyLibrary"], //option to tell explicitly where UI5 projects are relative to CWD, useful for CAP projects. See "Proxy workspaces" section for more details "proxyWorkspaces": ["./MyFEApp1", "./MyFEApp2"], // This configuration entry tries to parse UI5 project from node_modules folder. Requires "-dbg.js" files and "manifest.json" to be there. "nodeProjects": ["my-node-library"] } } } ``` These are default values, which can be overriden. > In case of `libsToLoad` and `excludeFolderPatterns` all additional values which are added in package.json will be added to the default values, not rewritten. --- ### Parser instantiation logic Let's introduce two terms which will be used here: - **CWD** - current working directory, or the root folder of the project which is opened in the VSCode. - **Workspace** - UI5 workspace, or the folder which has `manifest.json` in it. ``` --- CWD --- ├── webapp --- Workspace 1 --- │ ├── Component.js │ └── manifest.json ├── library --- Workspace 2 --- │ ├── library.js │ └── manifest.json └── package.json ``` The basic way for instantiating the parser looks as follows: - Read `package.json` in `CWD` and use it as a configuration source - Read all `Workspaces` and create UI5 Parser instance for it, using `package.json` as configuration source from previous step - If `CWD` has `tsconfig.json` and any `.ts` files, it is considered to be TS project. Otherwise it's JS project. > **Important!** Take in mind that nested projects are not supported anymore, which means that there can be no folders with such structure: ``` ├── webapp │ ├── library │ │ ├── library.js │ │ └── manifest.json │ ├── Component.js │ └── manifest.json ``` > The structure which will work as expected: ``` ├── library │ ├── library.js │ └── manifest.json ├── webapp │ ├── Component.js │ └── manifest.json ``` --- #### Additional Workspaces If there is a e.g. library outside of the `CWD`, checkout `additionalWorkspaces` config for `ui5parser`. Example: ``` ├── MyApp (CWD) │ │ ├── webapp │ │ │ ├── manifest.json │ │ │ └── Component.js │ └── package.json ├── MyLibrary (Outside of CWD) │ │ ├── src │ │ │ ├── manifest.json │ │ │ └── library.js │ └── package.json └── tsconfig.json ``` To make this work, corresponding entry in `package.json` should be added ```json "ui5": { "ui5parser": { "additionalWorkspaces" : ["../MyLibrary"] } } ``` --- #### Proxy Workspaces There are cases when project is mixed, meaning that one folder may contain many different projects inside, non-ui5 as well. Most frequent case would be CAP project with both backend and frontend in one folder. Example: ``` ├── frontend │ ├── webapp │ │ └── manifest.json │ ├── package.json (<- this file will be used as configuration source after proxyWorkspaces is configured) │ └── tsconfig.json ├── backend │ ├── Whatever.js │ └── package.json ├── package.json (<- proxyWorkspaces should be configured here) └── tsconfig.json ``` To make the parser work only for `frontend` folder, corresponding entry in `package.json` should be added ```json "ui5": { "ui5parser": { "proxyWorkspaces" : ["./frontend"] } } ``` What happens is that `CWD` is replaced with the new path from `proxyWorkspaces`, so at instantiation stage `package.json` and `tsconfig.json` from `frontend` folder will be used instead of root folder. --- #### Node projects There are cases when custom projects (e.g. libraries) installed via `npm` are used, for that purpose `nodeProjects` configuration entry was created. Example: `npm install my-custom-library` `package.json`: ```json "ui5": { "ui5parser": { "nodeProjects": ["my-custom-library"] } } ``` > **Important!** In order to get the project parsed properly, it should have `-dbg.js` files and `manifest.json`. Configuration will be inherited from main project (project in `CWD`). In other words, npm packages which were not built properly and have no `manifest.json` will not work. --- ## TS vs JS ### Initialization If `tsconfig.json` is found in the CWD and any `.ts` files are found in the workspace, parser considers that it's TS project.
`tsconfig.json` should be located in CWD. ### Folder exclusions For convenience purposes `UI5TSParser` ignores `src-gen` folder, because they contain transpiled JS/XML files, which can make the parser to think that source files are there. If build folder name is different, is should be added to `excludeFolderPatterns` in your `package.json`. If you are using older tooling with manual babel transpiler which generates `webapp` folder, it should be added to `excludeFolderPatterns` as well --- ## How to use Initialization process reads the metadata of standard SAPUI5 classes and parses all projects in CWD (Current working directory), it's encapsulated into `createInstances` method. For getting parsers just call it. ```ts const wsFolders = [new WorkspaceFolder("Absolute path to the workspace")]; const parsers = await ParserFactory.createInstances(wsFolders); ``` Necessary methods for getting information about the classes exists `ParserPool` class, which works with all parser instances. As an example, to get the parser for custom class, `getParserForCustomClass` can be used: ```ts const parser = ParserPool.getParserForCustomClass("com.test.any.class"); const UIClass = parser.classFactory.getUIClass("com.test.any.class"); ``` UIClass will have class metadata such as fields, methods, properties, aggregations, associations, events etc. > _TS only!_ For performance reasons TS parser doesn't parse types right away. If you want to load all type info such as method return type, parameter types etc, please use `UIClass.loadTypes()`
